Product Specifications
  • AttributesAttribute Value
  • ManufacturerZettler Magnetics
  • CategoryPower Transformers
  • PackagesTray
  • Standard Quantity20
  • Description
  • Size / Dimension35.2mm L x 29.8mm W
  • Mounting TypeThrough Hole
  • Termination StylePC Pin
  • Primary Winding(s)Single
  • Secondary Winding(s)Dual, Multiple Taps
  • Power - Max1.1VA
  • Voltage - Isolation2500V
  • Current - Output (Max)Parallel 180mA, Series 90mA
  • Voltage - Primary115V
  • Height - Seated (Max)1.043" (26.50mm)
  • Voltage - Secondary (Full Load)Parallel 6.3V, Series 12.6V
  • Center TapNo

VIEW ALL

Quality and Reliability

We supply 100% original and brand-new AH20012 from Zettler Magnetics only.
